Ceramic (Corundum: a-Al2O3) lined abrasion resistant straight pipe and fittings are lined with highly abrasion resistant ceramic,this kind of pipe are suitable for working under 700 ℃ for long time with service life span 10 times longer than normal steel pipe.

Applicable scope:  Power Plant, Mines Factories etc suffering from high wear, high sliding and high impact.

· Ceramic tile lined Pipe and Fitting

With self-locking shape ceramic tiles installed into the bend or pipe by inorganic adhesive and as well as stud welding. This solution can prevent the tiles from high abrasion as well as falling off in high temperature under 750℃.

Applicable scope:  high temperature and high abrasion material transport system.

· Ceramic composite pipe Features

1. Good wear resistance

Since the lining layer corundum ceramics (a-AL2O3) have hardness up to HRC90 and be suitable for electric power , mining, coal transportation and other industries fields ,it is ten times the wear life than common pipe.

2. Running resistance

SHS ceramic composite pipe due to the smooth inner surface and never rust, the inner surface smoothness better than any metal pipes,therefore, the tube has a running resistance and other characteristics which can reduce operating costs.

3. Corrosion-resistant ,anti- fouling

Since the steel ceramic layer (a-AL2O3), a neutral character. So with acid and seawater corrosion resistant and also has anti-scaling and other characteristics.

4. Heat resistance and good thermal performance

Since the alumina ceramics (a-AL2O3) have single crystal structure stability,which can make them operating under the temperature range of 700 ℃ for a long time.

5. Easy installation and construction

As the light weight of the tube with good welding performance. Which make it can be welded flanged , such fast connection  can reduce installation costs dramatically.
